Voltage Protector Socket with Display and Delay Time

Description

Key Features:

1. Auto Voltage Protection – Safeguards appliances from under-voltage (150V/180V preset) and over-voltage (260V) fluctuations.
2. Preset Delay Timer – Ensures stable operation with 5-second (short delay) and 180-second (extended delay) startup protection.
3. Dual Socket Design – Supports both 2-pin and 3-pin plugs for universal device compatibility.
4. High Power Capacity – Handles up to 2200W/10A, ideal for heavy-duty appliances like refrigerators, ACs, or heaters.
5. Robust Build Quality – Engineered for 220VAC power supply with 50/60Hz frequency tolerance.
6. Fixed Safety Settings – Preset voltage thresholds and timer intervals ensure hassle-free, error-proof operation.

Technical Specifications:

• Model: V261-D
• Rated Voltage: 220VAC
• Frequency: 50/60Hz
• Protection Ranges: Under-voltage (150V/180V), Over-voltage (260V)
• Max Load: 2200W / 10A
• Delay Timer: 5 seconds (short delay) / 180 seconds (long delay)
• Socket Types: 1× 3-pin, 1× 2-pin
